BOTTLE DRYER MACHINE   OUR PRODUCTS

Bottle Dryer Machine
 Salient Features
 Provided with four separate stations for inside wash and one station for outside wash.
 Washing sequences and positioning of washing stations can be interchanged as     required for liquid oral and injectables.
 A vary speed drive is provided for different output between 60 to 110 bottles per    minute.
 The specially designed cups are provided on the platform to accommodate any size of    bottle from 60ml to 500ml
 'GENEVA MECHANISM' eliminates carbon plate which avoids leakage and maintenance     is minimized.
 As the washing nozzles are stationary, the contamination of wash water is eliminated.

   Technical Specifications
Max. dia of bottle 85mm (30ml to 1000ml)
No. of spray nozzles 20
No. of bottle holders 64
Output 60 to 110 bottles/minute
No. of syringes 2 nos/4 nos (CGMP MODEL)
Tanks 2 nos of 75 litres each.
Main drive 1 HP/3 phase 1440 RPM
Electrical load 4 KW
Cups Suitable to bottles
Drive Vary Speed drive
Overall dimensions (in M.M) 1550Lx1550wx1270H
Net weight 650 kgs
Gross weight 1050 kgs


BOTTLE FILLING & SILLING MACHINE
 Salient Features
 The machine is suitable for the filling and sealing of the small mouth plastic bottle.It is specially fit for thw filling and sealing of the moftdrink,fermented milk,cool-fruits juice.

The machine is fit for the production of foods and uo to the healthy standards as the parts of the machine contacted with foods are made of stainless steel.

The machine runs automatically,programmable control,outo-checking,undo working without bottle feeding,but bottles-handing by manual.

 Running filling
   capacity : 3600-6000pcs/hr 100-180ml,or=40ml
   power supply :  380V./50HZ./3lines
   heating rower :  3.0KW
   motor :  0.75KW

   weight :  1500kg
   dimension :  3.1*1.2*2.22m
 Pump filling
   capacity :  2880-3600pcs/hr.(80-200ml)
   power supply :  380V./50HZ.
   heating rower :  1.2KW
   motor :  0.75KW
   weigh t:  700kg
   dimension :  2.5*1.0*2.0m
