 Salient Features |
 Machinicals Drive With Cam Profile
Servo Indexing
Easy Operation And Setting
User Friendly And Economic
Easy To Chang Over
Sepatate Station, Punching, Perforation Sealing
PRC,NFD Provision Optional |
|
| Salient Features |
Machinicals Drive With Cam Profile
Servo Indexing
Easy Operation And Setting
User Friendly And Economic
Easy To Chang Over
Sepatate Station, Punching, Perforation Sealing
PRC,NFD Provision Optional |
| |
| Technical Specifications |
PVC Bace Film Width Maximum – 230mm
PVC Film Thickness – 0.25 – 0.5
PVC Reel Diameter – Maximum 440mm
Aluminium Foil Width – 227mm
Aluminium Foil Thickness – 0.2 to 0.3
Aluminum Foil Reel Diamete – Maximum 200mm
Total Forming Area – Maximum 210mm
Indexing Lengt – Maximum 150mm
Pack Size Punched Out – Maximum 215mm
Forming Depth – Maximum 30mm
Width – 1050mm Lenth – 3500mm Hight – 1500mm
Wight – 1500kg |
| |
| Utilites |
Air Consumption – 250 Lit/ minute at 6 bar pressure
Cooling Water 120 Lit./ Hourat 14 Deg. C
Requirment – Base Film Dependent
Power – 5 Hp /440volt – 50h |
| |
| Note |
| It is recommended that machine is installed in airconditioned premises having room temperature of 22C to 26C to ensure efficient working
Specifications are indicative and we reserve the right to modify them without prior notice. |
| |
| |
